AZIMUTH & VTA ADJUSTMENT
The newly designed tonearm base allows you to adjust both the azimuth and the vertical tracking angle (VTA). The tonearm height can be continuously adjusted by loosening the two grub screws. These settings give you the option of adapting the tonearm to height changes allowing the use of different turntable mats or other cartridges to always achieve the best sound quality. Setting and experimenting with the VTA & Azimuth is crucial in extracting every last bit of performance out of your cartridges.
PRO Features
2M White
Made by Ortofon
Not only optically, also soundwise the perfect fit on the Debut PRO White.
VTA & Azimuth
Fully adjustable
The Debut PRO White comes with fully adjustable Azimuth & VTA. It offers you the possibility to modify your turntable as you want it.
33/45/78 RPM
High precision motor control
The playback speeds are electronically controlled with precision, which guarantees the most accurate and stable music reproduction. Change between speeds easily with the toggle switch.
Bearing block
Complete new design
The precision CNC milled and painted tonearm bearing parts are completely new and designed just for the PRO.
Special Platter
TPE damped & anti magnetic
The heavy aluminium platter has a ring made of TPE (thermoplastic elastomer) on the inside that helps to dampen all resonances and minimizes wow and flutter.
Metal Feet
Damped & height adjustable
The three height adjustable damped aluminium feet guarantee the perfect stand & massively reduce risk of acoustical feedback.
Belt driven
Vibration free
Vibrations from the motor are isolated from the platter due to the rubber belt and won't be picked up by the cartridge.
8,6" Tonearm
One-Piece Aluminium
This stiff and uniquely dampened aluminium tonearm ensures perfect tracking of the record groove.
Speed:
33, 45/(78) (electronic speed change)
Drive principle:
belt drive with electronic speed control
Platter:
300mm, die cast aluminium platter with TPE damping and felt mat
Platter bearing:
high precision stainless steel axle in bronze bushing
Wow & flutter:
33: +/-0,16%; 45: +/-0,14%
Speed drift:
33: +/-0,40%; 45: +/-0,50%
Signal to noise:
68dB
Tonearm:
8,6” one-piece aluminium tonearm
Effective arm length:
218,5 mm
Overhang:
18,5mm
Included accessories:
15V DC / 0,8A power supply, dust cover, 78 RPM round belt, 7‘‘ single adapter
Power consumption:
4W / 0W standby
Dimensions:
415 x 113 x 320mm (WxHxD)
Weight:
6 kg net
